Product Information
Deep cycle maintenance free gel battery.Our products can be used in UPS,solar street light,solar systems.
Product Parameters |
Factory long life battery gel solar for solar energy system 200ah solar gel batteries | |
Cell Per Unit | 6 |
Voltage Per Unit | 12V |
Capacity | 200AH@10hr-rate to 1.80V per cell @25°c |
Weight | 54KG |
Max. Discharge Current | 1000 A (5 sec) |
Internal Resistance | 3.5 M Omega |
Operating Temperature Range | Discharge: -40°c~50°c |
Charge: 0°c~50°c | |
Storage: -40°c~60°c | |
Normal Operating | 25°c±5°c |
Float charging | 13.6 to 14.8 VDC/unit Average at 25°c |
Recommended Maximum Charging Current | 20 A |
Equalization | 14.6 to 14.8 VDC/unit Average at 25°c |
Self Discharge | Batteries can be stored for more than 6 months at 25°c. Self-discharge ratio less than 3% per month at 25°c. Please charge batteries before using. |
Terminal | Terminal F5/F11 |
Container Material | A.B.S. UL94-HB, UL94-V0 Optional |
Product Specification |
Product Information
Deep cycle maintenance free gel battery.Our products can be used in UPS,solar street light,solar systems.
Product Parameters |
Factory long life battery gel solar for solar energy system 200ah solar gel batteries | |
Cell Per Unit | 6 |
Voltage Per Unit | 12V |
Capacity | 200AH@10hr-rate to 1.80V per cell @25°c |
Weight | 54KG |
Max. Discharge Current | 1000 A (5 sec) |
Internal Resistance | 3.5 M Omega |
Operating Temperature Range | Discharge: -40°c~50°c |
Charge: 0°c~50°c | |
Storage: -40°c~60°c | |
Normal Operating | 25°c±5°c |
Float charging | 13.6 to 14.8 VDC/unit Average at 25°c |
Recommended Maximum Charging Current | 20 A |
Equalization | 14.6 to 14.8 VDC/unit Average at 25°c |
Self Discharge | Batteries can be stored for more than 6 months at 25°c. Self-discharge ratio less than 3% per month at 25°c. Please charge batteries before using. |
Terminal | Terminal F5/F11 |
Container Material | A.B.S. UL94-HB, UL94-V0 Optional |
Product Specification |
1). What's kinds of battery will you provide?
We have two type of vrla battery: AGM battery, agm deep cycle battery and Gel battery.There are many different model battery here, we can supply12v 100ah and 12v 150ah deep cycle battery even 250ah battery, and lithium battery,12v 24Ah -130Ah.
2). Your battery can meet CE RoHS requirements?
Our battery are with the certificate of CE/RoHS.
3). Can we change the color based on the original?
Yes, the color can be customer-made according to your requirement.
4). Can you print my picture or logo on the battery cover?
Yes, OEM is available,we can print your picture or logo on the battery case, and you can offer your logo.
5). What kind of guarantee you give?
Our battery products can be used for more than 3 years. For AGM deep cycle battery our warranty time is 13 Months and for GEL battery warranty time is 3years.If it has quality problem during the warranty time we will change new battery for you.
1). What's kinds of battery will you provide?
We have two type of vrla battery: AGM battery, agm deep cycle battery and Gel battery.There are many different model battery here, we can supply12v 100ah and 12v 150ah deep cycle battery even 250ah battery, and lithium battery,12v 24Ah -130Ah.
2). Your battery can meet CE RoHS requirements?
Our battery are with the certificate of CE/RoHS.
3). Can we change the color based on the original?
Yes, the color can be customer-made according to your requirement.
4). Can you print my picture or logo on the battery cover?
Yes, OEM is available,we can print your picture or logo on the battery case, and you can offer your logo.
5). What kind of guarantee you give?
Our battery products can be used for more than 3 years. For AGM deep cycle battery our warranty time is 13 Months and for GEL battery warranty time is 3years.If it has quality problem during the warranty time we will change new battery for you.
